Sheet Metal Design Feature

 The features have the nature of parameterization, and their features are expressed in the way of parameters. Engineers establish a feature library in advance, which includes the features of parts commonly processed by sheet metal, such as flat plates, holes and grooves of various methods. Planning is to first input all the information of parts, select the matrix features in the feature library, generate matrix features, and take this as the basis for feature equipment modeling. Then the required features are selected from the feature library, the feature parameters and positioning parameters are given through the feature parameter table and positioning parameter table, and the feature equipment is carried out to establish the shape feature model.  Click here to contact JIATONG
